| Supported operating systems |
Windows® 10 (32-bit / 64-bit), Windows® 8 / 8.1 (32-bit / 64-bit), Windows® 7 (32-bit / 64-bit), Windows Vista® (32-bit / 64-bit), Windows Server® 2016 (64-bit), Windows Server® 2012 R2 (64-bit), Windows Server® 2012 (32-bit / 64-bit), Windows Server® 2008 R2 (64-bit), Windows Server® 2008 (32-bit / 64-bit), Linux Ubuntu
|
| Scanner Type |
Automatic Document Feeder (ADF) and Flatbed |
| Scanning Modes |
Simplex / Duplex, Color / Grayscale / Monochrome |
| Image Sensor Type |
Single line CMOS-CIS x 2 (Front / Flatbed x 1, Back x 1) |
| Light Source |
R, G, B LED x 2 (Front / Flatbed x 1, Back x 1) |
| Multifeed detection |
Ultrasonic Multi-feed Detection Sensor x 1 |
| Document size |
ADF |
Maximum |
216 x 356 mm (8.5 x 14 in.) |
| Minimum |
114 x 140 mm (4.5 x 5.5 in.) |
Long page scanning
|
216 x 3,048 mm (8.5 x 120 in.) |
| Flatbed |
Maximum |
216 x 297 mm (8.5 x 11.7 in.) |
| Minimum |
25.4 x 25.4 mm (1 x 1 in.) |
Paperweight
(Thickness)
|
Paper |
52 to 127 g/m2 (14 to 34 lb) |
| Plastic Card |
Not Support |
| Carrier sheet |
Not Support |
Scanning speed
(A4, Portrait)
|
ADF |
Colour
|
Simplex: 25 ppm (200 dpi / 300 dpi)
Duplex: 50 ipm (200 dpi / 300 dpi) |
Grayscale
|
Monochrome
|
| Flatbed |
Colour
|
4 Seconds (200 dpi / 300 dpi) |
Grayscale
|
Monochrome
|
Paper chute capacity (A4 Portrait)
|
50 sheets (A4: 80 g/m2 or 21 lb) |
| Expected daily volume |
3,000 sheets/day |
| Background colors |
ADF |
White |
| Flatbed |
Black |
| Optical Resolution |
600 dpi |
Output Resolution
|
Color (24-bit) |
50 dpi to 600 dpi (adjustable by 1 dpi increments), 1,200 dpi (driver)
|
| Grayscale (8-bit) |
| Monochrome (1-bit) |
Output format
|
Color |
24-bit |
| Grayscale |
8-bit |
| Monochrome |
1-bit |
| Internal video processing |
65,536 levels (16-bit) |
| Interface |
USB2.0 / USB 1.1 |
| Connector shape |
B type |
| Image processing function |
Image emphasis, Error diffusion, Dither, Dynamic threshold (iDTC), Static threshold, Advanced DTC, SDTC, De-Screen, Dropout color(Red, Green, Blue, White, None, Saturation, Custom), Automatic color detection, Multi-image output, Blank page detection, sRGB Output, Split image, Vertical streaks reduction, Edge Filler, Automatic page size detection |
| Power requirement |
AC 100 V to 240 V ± 10% |
| Power consumption |
Operating: 16 W or less
Sleep mode: 2.9 W or less
Auto standby (OFF) mode: 0.5 W or less |
| Operating environment |
Temperature: 5 to 35 °C (41 to 95 °F)
Relative humidity: 20 to 80% (Non-condensing) |
Dimensions: Width x Depth x Height
|
454 mm x 331 mm x 129 mm (17.9 in. x 13 in. x 5.1 in.) |
| Weight |
4.3 kg (9.5 lb) or less |
| Included software / drivers |
PaperStream IP for SP Series driver (TWAIN/TWAIN x64/ISIS), WIA Driver, PaperStream Capture Lite, Software Operation Panel, Error Recovery Guide, Presto!™ PageManager™, ABBYY™ FineReader™ Sprit Scanner Central Admin |
| Environmental compliance |
ENERGY STAR® and RoHS |
| Included items |
